News2013/07/01
SHINING E&E INDUSTRIAL CO., LTD. Pluggable Solutions.
SHINING E&E INDUSTRIAL CO., LTD. provide Pluggable Solutions for Current and Voltage Transformers DIN-rail Terminal Blocks. with touch-proof, pre-wired assemblies to streamline and eliminate wiring errors during panel- and machine-building. The blocks support diverse industries/applications in process, building automation, traffic engineering and more....
A system with modular base terminals and connectors allows universal use. Application-specific circuit tasks can be combined.
SHINING E & E INDUSTRIAL CO., LTD. Provides the following advantages:
- Rated voltage/current: 600V/10A~400A.
- DIN Rail: 35mm.
- Assembly for any poles.
- Rating: 600V, 10A
- Size: 25.8*38*28mm (L*W*H),
- Wire Size: 1.6 mm2 / AWG 16
- Screw Size: M3
- Molded from UL94-V2 material with excellent flame- and shock-resistance
- Sectional or one-piece construction. Easy and Flexible to form multipole assembly.
- Panel Mounting or standard 35mm DIN Rail Mounting available.
- Marking paper strips and protective covers are available.
- Excellent for switchboard panel, control consoles, small motors, transformers, air conditioners, power distribution and similar applications.
If you wanna know more about SHINING E & E INDUSTRIAL CO., LTD.'s Products, please visit our website. Would get more information, get more for your product solution.
